Find Your DIN 916 Cup Point Set Screw Size
Compare hex socket cup point set screws by material, thread diameter, pitch and length. Open a material group to see the listed size combinations.
All dimensions are in millimetres. Choose the diameter, pitch and length from the same row. On mobile, swipe the table sideways to view every column.
304 Stainless Steel · 104 catalogue items
| Thread diameter | Pitch (mm) | Thread / marking | Available lengths (mm) |
|---|---|---|---|
| M2 | 0.4 | Full thread Unmarked |
2 · 3 · 4 · 5 · 6 · 8 · 10 · 12 |
| M2.5 | 0.45 | Full thread Unmarked |
2 · 3 · 4 · 5 · 6 · 8 · 10 · 12 |
| M3 | 0.5 | Full thread Unmarked |
3 · 4 · 5 · 6 · 8 · 10 · 12 · 16 · 20 |
| M4 | 0.7 | Full thread Unmarked |
4 · 5 · 6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 |
| M5 | 0.8 | Full thread Unmarked |
5 · 6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 |
| M6 | 1 | Full thread Unmarked |
6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M8 | 1.25 | Full thread Unmarked |
6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M10 | 1.5 | Full thread Unmarked |
8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M12 | 1.75 | Full thread Unmarked |
10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 · 55 · 60 |
| M16 | 2 | Full thread Unmarked |
12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 · 55 · 60 |
316 Stainless Steel · 84 catalogue items
| Thread diameter | Pitch (mm) | Thread / marking | Available lengths (mm) |
|---|---|---|---|
| M3 | 0.5 | Full thread Unmarked |
3 · 4 · 5 · 6 · 8 · 10 · 12 · 16 · 20 |
| M4 | 0.7 | Full thread Unmarked |
4 · 5 · 6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 |
| M5 | 0.8 | Full thread Unmarked |
4 · 5 · 6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 |
| M6 | 1 | Full thread Unmarked |
6 · 8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M8 | 1.25 | Full thread Unmarked |
8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M10 | 1.5 | Full thread Unmarked |
8 · 10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M12 | 1.75 | Full thread Unmarked |
10 · 12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
| M16 | 2 | Full thread Unmarked |
12 · 16 · 20 · 25 · 30 · 35 · 40 · 45 · 50 |
Select the Right Specification
The current catalogue lists 304 stainless steel from M2 to M16 and 316 from M3 to M16. Length options differ by material and diameter; use the exact combinations above.
Confirm socket dimensions, cup point geometry and the required material documentation for your assembly. Include any hardness or mechanical requirements with the enquiry; these are not specified in the source records.
Fast Dispatch for Stocked Items
Items available in Tongming stock can usually be dispatched in around 3 days. Stock and dispatch timing are confirmed with your quotation.
Send Your Specification
Include DIN 916, material, thread diameter, pitch, length and quantity. Attach a drawing if cup point dimensions, tolerances or inspection requirements are important.
Fastener supply experience since 2005. Nanjing Tongming provides experienced product coordination and competitive quotations for project and repeat purchasing.
Catalogue listing does not indicate live stock. Dimensions and documentation are confirmed for the quoted item.
