Choose Your Closed-End Flat Head Rivet Nuts
TONG 304 stainless steel rivet nuts with a flat head, vertically knurled round body and closed end. The supplier lists this blind-hole series in five metric coarse-thread sizes: M4, M5, M6, M8 and M10.
Dimensions and panel thickness are in millimetres. Match the thread, catalogue length and panel-thickness range from the same row. On mobile, swipe the table sideways to view all columns.
304 Stainless Steel · 5 catalogue sizes
| Internal thread | Catalogue length (mm) | Panel thickness (mm) | Item reference |
|---|---|---|---|
| M4 | 16 | 0.5–2.0 | 273611 |
| M5 | 17 | 0.5–2.0 | 273612 |
| M6 | 19.2 | 0.5–2.5 | 273613 |
| M8 | 21.5 | 0.5–2.5 | 273614 |
| M10 | 27 | 1.0–3.5 | 273615 |
Specify the Closed-End Pattern
This product has a closed bottom. Select the open-end or closed-end pattern explicitly when requesting a quotation, because the catalogue lengths and installation requirements differ.
Confirm the mounting-hole diameter, head dimensions, numerical thread pitch, usable thread depth and installation tooling against the selected item’s drawing. A closed end alone does not establish a watertight or pressure-rated seal; no sealing or load rating is stated in these catalogue records.
Fast Dispatch for Stocked Items
Items available in Tongming stock can usually be dispatched in around 3 days. Stock and dispatch timing are confirmed with your quotation.
Request a Rivet Nut Quotation
Include TONG, 304 stainless steel, the closed-end flat-head pattern, thread size, catalogue length, panel thickness and quantity. Add the item reference or attach your drawing for an exact match.
Fastener supply experience since 2005. Nanjing Tongming provides experienced product coordination and competitive quotations for project and repeat purchasing.
Catalogue listing does not indicate live stock. Exact dimensions and documentation are confirmed for the quoted item.
